Description

Applicable Standards

1.Design and Manufacture

API 602, BS5352, ASME B16.34

2.Connection end Socket Weld End(SW):ASME B16.11

Threaded End(NPT):ASME B 1.20.1

Butt-Weld End(BW):ASME B 16.25

Flange End(RF/RTJ):ASME B 16.5

3. Test & Inspection

API 602, API 598

4. Design Description

Bolted Bonnet(BB),

Welded Bonnet(WB),

5. Main Materials:

A105,LF2,F5,F11,F22,

304(L),316(L),F347,F321,

F51,Alloy 20, Monel

Specification

No.PARTASTM Material


A105LF2F11F304(L)F316(L)F51
1BODYA105LF2F11F304(L)F316(L)F51
2DISCF6aF6aF6a+STLF304(L)F316(L)F51
3SEAT410410410+STL304(L)316(L)F51
4GASKET304+Graphite304+Graphite316(L)+Graphite316(L)+Graphite
5BONNETA105LF2F11F304(L)F316(L)F51
6BOLTB7L7B16B8(M)B8(M)B8M
7PIN410304(L)316(L)F51
8HINGE304304(L)316(L)F51
9NUTA194 2H88M8M
10SPRINGSs316

If you want to order the one piece body, please contact sale department



CL150-300-600
Size(NPS)R.P1-23-411.1/41.1/22
Face To FaceCL150L(RF)108118127140165203
CL300153178203216229267
CL600165191216229241292
HeightCL150H77819395103118
CL300/600617884101120133
Flow Port DiameterLift type10.513.517222834
(d)Swing type10.313.518232936
WeightCL150Lift type3.64.68.59.212.514.8
Swing type
CL300Lift type3.74.88.89.613.717.8
Swing type
CL600Lift type45.89.510.415.624.5
Swing type



CL800Bolted Bonnet/Welded Bonnet, Full Port/Reduced Port,Outside Screw and Yoke(OS&Y).Threaded, Butt Weld, Socket Weld.Design:API602
Size(NPS)R.P1-23-411.1/41.1/22

F.P3-81-23-411.1/41.1/22
Face To FaceLLift type7992111120152172220


Swing type7992111120120140178
HeightHLift type61617884103118132


Swing type61617884101120133
Flow Port DiameterdLift type10.513.51722283443


Swing type10.313.51823293645
WeightLift type1.51.73.34.26.310.512.5

Swing type1.51.73.34.258.510.9



CL900-1500RF/RTJ Flange End, Design: API 602
Size(NPS)R.P1-23-411.1/41.1/22
Face To FaceL(RF)216229254279305368


(RTJ)216229254279305371
HeightH819395101118130

dLift type10.513.517222834


Swing type10.313.518232936
Weight(CL1500)5.26.810.514.51824

NOTE:If you want to order the one piece body, please contact sale department,

CL900 and CL1500 have the same face to face dimension.



CL900-1500Pressure Seal Bonnet. Full Port/Reduced Port, Outside Screw and Yoke(OS&Y)
Threaded, Butt Weld, Socket Weld, Design: ASME B16.34
Size(NPS)R.P1-23-411.1/41.1/22

F.P3-81-23-411.1/41.1/2
Face To FaceLLift type92111120152172220


Swing type92111120120140178
HeightHLift type787884103118132


Swing type787884101120133
Flow Port DiameterdLift type10.513.517222834


Swing type10.313.518232936
WeightLift type3.43.34.26.310.512.5

Swing type3.43.34.258.510.9
