1. Pressure: 150lb, 200lb, 300lb
2. Media: seawater, oil, liquefied gas
3. Temperature: water below 120℃，oil, gas, steam below 220℃
4. End connection std: G, RC, RP, NPT, BSPT, BSP, DIN259/2999
| DN | SIZE | D | L | H | G |  |
| DN15 | 1-2 | 15 | 72 | 55 | 102 | |
| DN20 | 3-4 | 20 | 82 | 60 | 120 | |
| DN25 | 1 | 25 | 90 | 70 | 140 | |
| DN32 | 1 1/4 | 32 | 112 | 85 | 161 | |
| DN40 | 1 1/2 | 40 | 120 | 90 | 180 | |
| DN50 | 2 | 50 | 145 | 110 | 180 | |
| DN65 | 2 1/2 | 65 | 180 | 115 | 215 | |
| DN80 | 3 | 80 | 205 | 145 | 240 | |
| DN100 | 4 | 100 | 270 | 155 | 300 |
